Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols > Class Template Reference

#include <SparseBlock.h>

Inheritance diagram for Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >:
Inheritance graph
[legend]
Collaboration diagram for Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >:
Collaboration graph
[legend]

List of all members.

Public Types

enum  { IsRowMajor = internal::traits<BlockType>::IsRowMajor }

Public Member Functions

 sparse_matrix_block_impl (SparseMatrixType &xpr, Index i)
 sparse_matrix_block_impl (SparseMatrixType &xpr, Index startRow, Index startCol, Index blockRows, Index blockCols)
template<typename OtherDerived >
BlockType & operator= (const SparseMatrixBase< OtherDerived > &other)
BlockType & operator= (const BlockType &other)
const Scalar * valuePtr () const
Scalar * valuePtr ()
const StorageIndex * innerIndexPtr () const
StorageIndex * innerIndexPtr ()
const StorageIndex * outerIndexPtr () const
StorageIndex * outerIndexPtr ()
const StorageIndex * innerNonZeroPtr () const
StorageIndex * innerNonZeroPtr ()
bool isCompressed () const
Scalar & coeffRef (Index row, Index col)
const Scalar coeff (Index row, Index col) const
const Scalar coeff (Index index) const
const Scalar & lastCoeff () const
EIGEN_STRONG_INLINE Index rows () const
EIGEN_STRONG_INLINE Index cols () const
const SparseMatrixType & nestedExpression () const
SparseMatrixType & nestedExpression ()
Index startRow () const
Index startCol () const
Index blockRows () const
Index blockCols () const

Protected Types

enum  { OuterSize = IsRowMajor ? BlockRows : BlockCols }
typedef Base::IndexVector IndexVector

Protected Attributes

internal::ref_selector
< SparseMatrixType >
::non_const_type 		m_matrix
Index m_outerStart
const
internal::variable_if_dynamic
< Index, OuterSize > 		m_outerSize

Private Types

typedef internal::remove_all
< typename
SparseMatrixType::Nested >
::type 		_MatrixTypeNested
typedef Block
< SparseMatrixType, BlockRows,
BlockCols, true > 		BlockType
typedef SparseCompressedBase
< Block< SparseMatrixType,
BlockRows, BlockCols, true > > 		Base

Detailed Description

template<typename SparseMatrixType, int BlockRows, int BlockCols>
class Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >

Definition at line 96 of file SparseBlock.h.

Member Typedef Documentation

template<typename SparseMatrixType, int BlockRows, int BlockCols>
typedef internal::remove_all<typename SparseMatrixType::Nested>::type Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::_MatrixTypeNested [private]

Definition at line 99 of file SparseBlock.h.

template<typename SparseMatrixType, int BlockRows, int BlockCols>
typedef SparseCompressedBase<Block<SparseMatrixType,BlockRows,BlockCols,true> > Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::Base [private]

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Reimplemented in Eigen::BlockImpl< const SparseMatrix< _Scalar, _Options, _StorageIndex >, BlockRows, BlockCols, true, Sparse >, and Eigen::BlockImpl< SparseMatrix< _Scalar, _Options, _StorageIndex >, BlockRows, BlockCols, true, Sparse >.

Definition at line 101 of file SparseBlock.h.

template<typename SparseMatrixType, int BlockRows, int BlockCols>
typedef Block<SparseMatrixType, BlockRows, BlockCols, true> Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::BlockType [private]

Definition at line 100 of file SparseBlock.h.

template<typename SparseMatrixType, int BlockRows, int BlockCols>
typedef Base::IndexVector Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::IndexVector [protected]

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 107 of file SparseBlock.h.

Member Enumeration Documentation

template<typename SparseMatrixType, int BlockRows, int BlockCols>
anonymous enum
Enumerator:
IsRowMajor

Definition at line 104 of file SparseBlock.h.

{ IsRowMajor = internal::traits<BlockType>::IsRowMajor };
template<typename SparseMatrixType, int BlockRows, int BlockCols>
anonymous enum [protected]
Enumerator:
OuterSize

Definition at line 108 of file SparseBlock.h.

{ OuterSize = IsRowMajor ? BlockRows : BlockCols };

Constructor & Destructor Documentation

template<typename SparseMatrixType, int BlockRows, int BlockCols>
Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::sparse_matrix_block_impl ( SparseMatrixType &  xpr,
Index  i
) [inline]

Definition at line 111 of file SparseBlock.h.

      : m_matrix(xpr), m_outerStart(convert_index(i)), m_outerSize(OuterSize)
    {}
template<typename SparseMatrixType, int BlockRows, int BlockCols>
Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::sparse_matrix_block_impl ( SparseMatrixType &  xpr,
Index  startRow,
Index  startCol,
Index  blockRows,
Index  blockCols
) [inline]

Definition at line 115 of file SparseBlock.h.

      : m_matrix(xpr), m_outerStart(convert_index(IsRowMajor ? startRow : startCol)), m_outerSize(convert_index(IsRowMajor ? blockRows : blockCols))
    {}

Member Function Documentation

template<typename SparseMatrixType, int BlockRows, int BlockCols>
Index Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::blockCols ( ) const [inline]

Definition at line 272 of file SparseBlock.h.

{ return IsRowMajor ? m_matrix.cols() : m_outerSize.value(); }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
Index Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::blockRows ( ) const [inline]

Definition at line 271 of file SparseBlock.h.

{ return IsRowMajor ? m_outerSize.value() : m_matrix.rows(); }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
const Scalar Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::coeff ( Index  row,
Index  col
) const [inline]

Definition at line 244 of file SparseBlock.h.

    {
      return m_matrix.coeff(row + (IsRowMajor ? m_outerStart : 0), col + (IsRowMajor ? 0 :  m_outerStart));
    }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
const Scalar Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::coeff ( Index  index) const [inline]

Definition at line 249 of file SparseBlock.h.

    {
      return m_matrix.coeff(IsRowMajor ? m_outerStart : index, IsRowMajor ? index :  m_outerStart);
    }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
Scalar& Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::coeffRef ( Index  row,
Index  col
) [inline]

Definition at line 239 of file SparseBlock.h.

    {
      return m_matrix.coeffRef(row + (IsRowMajor ? m_outerStart : 0), col + (IsRowMajor ? 0 :  m_outerStart));
    }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
EIGEN_STRONG_INLINE Index Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::cols ( void  ) const [inline]
Returns:
the number of columns.
See also:
rows()

Reimplemented from Eigen::SparseMatrixBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 265 of file SparseBlock.h.

{ return IsRowMajor ? m_matrix.cols() : m_outerSize.value(); }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
const StorageIndex* Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::innerIndexPtr ( ) const [inline]
Returns:
a const pointer to the array of inner indices. This function is aimed at interoperability with other libraries.
See also:
valuePtr(), outerIndexPtr()

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 222 of file SparseBlock.h.

    { return m_matrix.innerIndexPtr(); }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
StorageIndex* Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::innerIndexPtr ( ) [inline]
Returns:
a non-const pointer to the array of inner indices. This function is aimed at interoperability with other libraries.
See also:
valuePtr(), outerIndexPtr()

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 224 of file SparseBlock.h.

    { return m_matrix.innerIndexPtr(); }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
const StorageIndex* Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::innerNonZeroPtr ( ) const [inline]
Returns:
a const pointer to the array of the number of non zeros of the inner vectors. This function is aimed at interoperability with other libraries.
Warning:
it returns the null pointer 0 in compressed mode

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 232 of file SparseBlock.h.

    { return isCompressed() ? 0 : (m_matrix.innerNonZeroPtr()+m_outerStart); }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
StorageIndex* Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::innerNonZeroPtr ( ) [inline]
Returns:
a non-const pointer to the array of the number of non zeros of the inner vectors. This function is aimed at interoperability with other libraries.
Warning:
it returns the null pointer 0 in compressed mode

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 234 of file SparseBlock.h.

    { return isCompressed() ? 0 : (m_matrix.innerNonZeroPtr()+m_outerStart); }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
bool Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::isCompressed ( ) const [inline]
Returns:
whether *this is in compressed form.

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 237 of file SparseBlock.h.

{ return m_matrix.innerNonZeroPtr()==0; }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
const Scalar& Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::lastCoeff ( ) const [inline]

Definition at line 254 of file SparseBlock.h.

    {
      EIGEN_STATIC_ASSERT_VECTOR_ONLY(sparse_matrix_block_impl);
      eigen_assert(Base::nonZeros()>0);
      if(m_matrix.isCompressed())
        return m_matrix.valuePtr()[m_matrix.outerIndexPtr()[m_outerStart+1]-1];
      else
        return m_matrix.valuePtr()[m_matrix.outerIndexPtr()[m_outerStart]+m_matrix.innerNonZeroPtr()[m_outerStart]-1];
    }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
const SparseMatrixType& Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::nestedExpression ( ) const [inline]

Definition at line 267 of file SparseBlock.h.

{ return m_matrix; }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
SparseMatrixType& Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::nestedExpression ( ) [inline]

Definition at line 268 of file SparseBlock.h.

{ return m_matrix; }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
template<typename OtherDerived >
BlockType& Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::operator= ( const SparseMatrixBase< OtherDerived > &  other) [inline]

Reimplemented from Eigen::SparseMatrixBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 120 of file SparseBlock.h.

    {
      typedef typename internal::remove_all<typename SparseMatrixType::Nested>::type _NestedMatrixType;
      _NestedMatrixType& matrix = m_matrix;
      // This assignment is slow if this vector set is not empty
      // and/or it is not at the end of the nonzeros of the underlying matrix.

      // 1 - eval to a temporary to avoid transposition and/or aliasing issues
      Ref<const SparseMatrix<Scalar, IsRowMajor ? RowMajor : ColMajor, StorageIndex> > tmp(other.derived());
      eigen_internal_assert(tmp.outerSize()==m_outerSize.value());

      // 2 - let's check whether there is enough allocated memory
      Index nnz           = tmp.nonZeros();
      Index start         = m_outerStart==0 ? 0 : matrix.outerIndexPtr()[m_outerStart]; // starting position of the current block
      Index end           = m_matrix.outerIndexPtr()[m_outerStart+m_outerSize.value()]; // ending position of the current block
      Index block_size    = end - start;                                                // available room in the current block
      Index tail_size     = m_matrix.outerIndexPtr()[m_matrix.outerSize()] - end;

      Index free_size     = m_matrix.isCompressed()
                          ? Index(matrix.data().allocatedSize()) + block_size
                          : block_size;

      bool update_trailing_pointers = false;
      if(nnz>free_size)
      {
        // realloc manually to reduce copies
        typename SparseMatrixType::Storage newdata(m_matrix.data().allocatedSize() - block_size + nnz);

        internal::smart_copy(m_matrix.valuePtr(),       m_matrix.valuePtr() + start,      newdata.valuePtr());
        internal::smart_copy(m_matrix.innerIndexPtr(),  m_matrix.innerIndexPtr() + start, newdata.indexPtr());

        internal::smart_copy(tmp.valuePtr(),      tmp.valuePtr() + nnz,       newdata.valuePtr() + start);
        internal::smart_copy(tmp.innerIndexPtr(), tmp.innerIndexPtr() + nnz,  newdata.indexPtr() + start);

        internal::smart_copy(matrix.valuePtr()+end,       matrix.valuePtr()+end + tail_size,      newdata.valuePtr()+start+nnz);
        internal::smart_copy(matrix.innerIndexPtr()+end,  matrix.innerIndexPtr()+end + tail_size, newdata.indexPtr()+start+nnz);

        newdata.resize(m_matrix.outerIndexPtr()[m_matrix.outerSize()] - block_size + nnz);

        matrix.data().swap(newdata);

        update_trailing_pointers = true;
      }
      else
      {
        if(m_matrix.isCompressed())
        {
          // no need to realloc, simply copy the tail at its respective position and insert tmp
          matrix.data().resize(start + nnz + tail_size);

          internal::smart_memmove(matrix.valuePtr()+end,      matrix.valuePtr() + end+tail_size,      matrix.valuePtr() + start+nnz);
          internal::smart_memmove(matrix.innerIndexPtr()+end, matrix.innerIndexPtr() + end+tail_size, matrix.innerIndexPtr() + start+nnz);

          update_trailing_pointers = true;
        }

        internal::smart_copy(tmp.valuePtr(),      tmp.valuePtr() + nnz,       matrix.valuePtr() + start);
        internal::smart_copy(tmp.innerIndexPtr(), tmp.innerIndexPtr() + nnz,  matrix.innerIndexPtr() + start);
      }

      // update outer index pointers and innerNonZeros
      if(IsVectorAtCompileTime)
      {
        if(!m_matrix.isCompressed())
          matrix.innerNonZeroPtr()[m_outerStart] = StorageIndex(nnz);
        matrix.outerIndexPtr()[m_outerStart] = StorageIndex(start);
      }
      else
      {
        StorageIndex p = StorageIndex(start);
        for(Index k=0; k<m_outerSize.value(); ++k)
        {
          Index nnz_k = tmp.innerVector(k).nonZeros();
          if(!m_matrix.isCompressed())
            matrix.innerNonZeroPtr()[m_outerStart+k] = StorageIndex(nnz_k);
          matrix.outerIndexPtr()[m_outerStart+k] = p;
          p += nnz_k;
        }
      }

      if(update_trailing_pointers)
      {
        StorageIndex offset = internal::convert_index<StorageIndex>(nnz - block_size);
        for(Index k = m_outerStart + m_outerSize.value(); k<=matrix.outerSize(); ++k)
        {
          matrix.outerIndexPtr()[k] += offset;
        }
      }

      return derived();
    }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
BlockType& Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::operator= ( const BlockType &  other) [inline]

Definition at line 212 of file SparseBlock.h.

    {
      return operator=<BlockType>(other);
    }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
const StorageIndex* Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::outerIndexPtr ( ) const [inline]
Returns:
a const pointer to the array of the starting positions of the inner vectors. This function is aimed at interoperability with other libraries.
Warning:
it returns the null pointer 0 for SparseVector
See also:
valuePtr(), innerIndexPtr()

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 227 of file SparseBlock.h.

    { return m_matrix.outerIndexPtr() + m_outerStart; }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
StorageIndex* Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::outerIndexPtr ( ) [inline]
Returns:
a non-const pointer to the array of the starting positions of the inner vectors. This function is aimed at interoperability with other libraries.
Warning:
it returns the null pointer 0 for SparseVector
See also:
valuePtr(), innerIndexPtr()

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 229 of file SparseBlock.h.

    { return m_matrix.outerIndexPtr() + m_outerStart; }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
EIGEN_STRONG_INLINE Index Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::rows ( void  ) const [inline]
Returns:
the number of rows.
See also:
cols()

Reimplemented from Eigen::SparseMatrixBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 264 of file SparseBlock.h.

{ return IsRowMajor ? m_outerSize.value() : m_matrix.rows(); }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
Index Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::startCol ( ) const [inline]

Definition at line 270 of file SparseBlock.h.

{ return IsRowMajor ? 0 : m_outerStart; }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
Index Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::startRow ( ) const [inline]

Definition at line 269 of file SparseBlock.h.

{ return IsRowMajor ? m_outerStart : 0; }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
const Scalar* Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::valuePtr ( ) const [inline]
Returns:
a const pointer to the array of values. This function is aimed at interoperability with other libraries.
See also:
innerIndexPtr(), outerIndexPtr()

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 217 of file SparseBlock.h.

    { return m_matrix.valuePtr(); }
template<typename SparseMatrixType, int BlockRows, int BlockCols>
Scalar* Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::valuePtr ( ) [inline]
Returns:
a non-const pointer to the array of values. This function is aimed at interoperability with other libraries.
See also:
innerIndexPtr(), outerIndexPtr()

Reimplemented from Eigen::SparseCompressedBase< Block< SparseMatrixType, BlockRows, BlockCols, true > >.

Definition at line 219 of file SparseBlock.h.

    { return m_matrix.valuePtr(); }

Member Data Documentation

template<typename SparseMatrixType, int BlockRows, int BlockCols>
internal::ref_selector<SparseMatrixType>::non_const_type Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::m_matrix [protected]

Definition at line 276 of file SparseBlock.h.

template<typename SparseMatrixType, int BlockRows, int BlockCols>
const internal::variable_if_dynamic<Index, OuterSize> Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::m_outerSize [protected]

Definition at line 278 of file SparseBlock.h.

template<typename SparseMatrixType, int BlockRows, int BlockCols>
Index Eigen::internal::sparse_matrix_block_impl< SparseMatrixType, BlockRows, BlockCols >::m_outerStart [protected]

Definition at line 277 of file SparseBlock.h.

The documentation for this class was generated from the following file:
 All Classes Namespaces Files Functions Variables Typedefs Enumerations Enumerator Friends Defines
