A sparse direct LU factorization and solver based on the SuperLU library. More...

#include <SuperLUSupport.h>

Inheritance diagram for Eigen::SuperLU< _MatrixType >:

Collaboration diagram for Eigen::SuperLU< _MatrixType >:

Public Types
typedef SuperLUBase < _MatrixType, SuperLU >	Base
typedef _MatrixType	MatrixType
typedef Base::Scalar	Scalar
typedef Base::RealScalar	RealScalar
typedef Base::StorageIndex	StorageIndex
typedef Base::IntRowVectorType	IntRowVectorType
typedef Base::IntColVectorType	IntColVectorType
typedef Base::PermutationMap	PermutationMap
typedef Base::LUMatrixType	LUMatrixType
typedef TriangularView < LUMatrixType, Lower\|UnitDiag >	LMatrixType
typedef TriangularView < LUMatrixType, Upper >	UMatrixType
Public Member Functions
	SuperLU ()
	SuperLU (const MatrixType &matrix)
	~SuperLU ()
void	analyzePattern (const MatrixType &matrix)
void	factorize (const MatrixType &matrix)
template<typename Rhs , typename Dest >
void	_solve_impl (const MatrixBase< Rhs > &b, MatrixBase< Dest > &dest) const
const LMatrixType &	matrixL () const
const UMatrixType &	matrixU () const
const IntColVectorType &	permutationP () const
const IntRowVectorType &	permutationQ () const
Scalar	determinant () const
Protected Member Functions
void	init ()
Private Member Functions
	SuperLU (SuperLU &)

Detailed Description

template<typename _MatrixType>
class Eigen::SuperLU< _MatrixType >

A sparse direct LU factorization and solver based on the SuperLU library.

This class allows to solve for A.X = B sparse linear problems via a direct LU factorization using the SuperLU library. The sparse matrix A must be squared and invertible. The vectors or matrices X and B can be either dense or sparse.

Template Parameters:

_MatrixType the type of the sparse matrix A, it must be a SparseMatrix<>

Warning:: This class is only for the 4.x versions of SuperLU. The 3.x and 5.x versions are not supported.

See also:: TutorialSparseSolverConcept, class SparseLU

Definition at line 462 of file SuperLUSupport.h.

Member Typedef Documentation

template<typename _MatrixType>

typedef SuperLUBase<_MatrixType,SuperLU> Eigen::SuperLU< _MatrixType >::Base

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 465 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef Base::IntColVectorType Eigen::SuperLU< _MatrixType >::IntColVectorType

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 471 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef Base::IntRowVectorType Eigen::SuperLU< _MatrixType >::IntRowVectorType

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 470 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef TriangularView<LUMatrixType, Lower|UnitDiag> Eigen::SuperLU< _MatrixType >::LMatrixType

Definition at line 474 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef Base::LUMatrixType Eigen::SuperLU< _MatrixType >::LUMatrixType

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 473 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef _MatrixType Eigen::SuperLU< _MatrixType >::MatrixType

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 466 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef Base::PermutationMap Eigen::SuperLU< _MatrixType >::PermutationMap

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 472 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef Base::RealScalar Eigen::SuperLU< _MatrixType >::RealScalar

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 468 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef Base::Scalar Eigen::SuperLU< _MatrixType >::Scalar

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 467 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef Base::StorageIndex Eigen::SuperLU< _MatrixType >::StorageIndex

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 469 of file SuperLUSupport.h.

template<typename _MatrixType>

typedef TriangularView<LUMatrixType, Upper> Eigen::SuperLU< _MatrixType >::UMatrixType

Definition at line 475 of file SuperLUSupport.h.

Constructor & Destructor Documentation

template<typename _MatrixType>

Eigen::SuperLU< _MatrixType >::SuperLU ( ) [inline]

Definition at line 480 of file SuperLUSupport.h.

: Base() { init(); }

template<typename _MatrixType>

Eigen::SuperLU< _MatrixType >::SuperLU ( const MatrixType & matrix ) [inline, explicit]

Definition at line 482 of file SuperLUSupport.h.

                                               : Base()
    {
      init();
      Base::compute(matrix);
    }

template<typename _MatrixType>

Eigen::SuperLU< _MatrixType >::~SuperLU ( ) [inline]

Definition at line 488 of file SuperLUSupport.h.

    {
    }

template<typename _MatrixType>

Eigen::SuperLU< _MatrixType >::SuperLU ( SuperLU< _MatrixType > & ) [inline, private]

Definition at line 583 of file SuperLUSupport.h.

{ }

Member Function Documentation

template<typename MatrixType >

template<typename Rhs , typename Dest >

void Eigen::SuperLU< MatrixType >::_solve_impl	(	const MatrixBase< Rhs > &	b,
		MatrixBase< Dest > &	dest
	)		const

Definition at line 623 of file SuperLUSupport.h.

{
  eigen_assert(m_factorizationIsOk && "The decomposition is not in a valid state for solving, you must first call either compute() or analyzePattern()/factorize()");

  const Index size = m_matrix.rows();
  const Index rhsCols = b.cols();
  eigen_assert(size==b.rows());

  m_sluOptions.Trans = NOTRANS;
  m_sluOptions.Fact = FACTORED;
  m_sluOptions.IterRefine = NOREFINE;


  m_sluFerr.resize(rhsCols);
  m_sluBerr.resize(rhsCols);

  Ref<const Matrix<typename Rhs::Scalar,Dynamic,Dynamic,ColMajor> > b_ref(b);
  Ref<const Matrix<typename Dest::Scalar,Dynamic,Dynamic,ColMajor> > x_ref(x);

  m_sluB = SluMatrix::Map(b_ref.const_cast_derived());
  m_sluX = SluMatrix::Map(x_ref.const_cast_derived());

  typename Rhs::PlainObject b_cpy;
  if(m_sluEqued!='N')
  {
    b_cpy = b;
    m_sluB = SluMatrix::Map(b_cpy.const_cast_derived());
  }

  StatInit(&m_sluStat);
  int info = 0;
  RealScalar recip_pivot_growth, rcond;
  SuperLU_gssvx(&m_sluOptions, &m_sluA,
                m_q.data(), m_p.data(),
                &m_sluEtree[0], &m_sluEqued,
                &m_sluRscale[0], &m_sluCscale[0],
                &m_sluL, &m_sluU,
                NULL, 0,
                &m_sluB, &m_sluX,
                &recip_pivot_growth, &rcond,
                &m_sluFerr[0], &m_sluBerr[0],
                &m_sluStat, &info, Scalar());
  StatFree(&m_sluStat);

  if(x.derived().data() != x_ref.data())
    x = x_ref;

  m_info = info==0 ? Success : NumericalIssue;
}

template<typename _MatrixType>

void Eigen::SuperLU< _MatrixType >::analyzePattern ( const MatrixType & matrix ) [inline]

Performs a symbolic decomposition on the sparcity of matrix.

This function is particularly useful when solving for several problems having the same structure.

See also:: factorize()

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 498 of file SuperLUSupport.h.

    {
      m_info = InvalidInput;
      m_isInitialized = false;
      Base::analyzePattern(matrix);
    }

template<typename MatrixType >

SuperLU< MatrixType >::Scalar Eigen::SuperLU< MatrixType >::determinant ( ) const

Definition at line 767 of file SuperLUSupport.h.

{
  eigen_assert(m_factorizationIsOk && "The decomposition is not in a valid state for computing the determinant, you must first call either compute() or analyzePattern()/factorize()");

  if (m_extractedDataAreDirty)
    this->extractData();

  Scalar det = Scalar(1);
  for (int j=0; j<m_u.cols(); ++j)
  {
    if (m_u.outerIndexPtr()[j+1]-m_u.outerIndexPtr()[j] > 0)
    {
      int lastId = m_u.outerIndexPtr()[j+1]-1;
      eigen_assert(m_u.innerIndexPtr()[lastId]<=j);
      if (m_u.innerIndexPtr()[lastId]==j)
        det *= m_u.valuePtr()[lastId];
    }
  }
  if(PermutationMap(m_p.data(),m_p.size()).determinant()*PermutationMap(m_q.data(),m_q.size()).determinant()<0)
    det = -det;
  if(m_sluEqued!='N')
    return det/m_sluRscale.prod()/m_sluCscale.prod();
  else
    return det;
}

template<typename MatrixType >

void Eigen::SuperLU< MatrixType >::factorize ( const MatrixType & matrix )

Performs a numeric decomposition of matrix

The given matrix must has the same sparcity than the matrix on which the symbolic decomposition has been performed.

See also:: analyzePattern()

Definition at line 587 of file SuperLUSupport.h.

{
  eigen_assert(m_analysisIsOk && "You must first call analyzePattern()");
  if(!m_analysisIsOk)
  {
    m_info = InvalidInput;
    return;
  }

  this->initFactorization(a);

  m_sluOptions.ColPerm = COLAMD;
  int info = 0;
  RealScalar recip_pivot_growth, rcond;
  RealScalar ferr, berr;

  StatInit(&m_sluStat);
  SuperLU_gssvx(&m_sluOptions, &m_sluA, m_q.data(), m_p.data(), &m_sluEtree[0],
                &m_sluEqued, &m_sluRscale[0], &m_sluCscale[0],
                &m_sluL, &m_sluU,
                NULL, 0,
                &m_sluB, &m_sluX,
                &recip_pivot_growth, &rcond,
                &ferr, &berr,
                &m_sluStat, &info, Scalar());
  StatFree(&m_sluStat);

  m_extractedDataAreDirty = true;

  // FIXME how to better check for errors ???
  m_info = info == 0 ? Success : NumericalIssue;
  m_factorizationIsOk = true;
}

template<typename _MatrixType>

void Eigen::SuperLU< _MatrixType >::init ( ) [inline, protected]

Reimplemented from Eigen::SuperLUBase< _MatrixType, SuperLU< _MatrixType > >.

Definition at line 570 of file SuperLUSupport.h.

    {
      Base::init();

      set_default_options(&this->m_sluOptions);
      m_sluOptions.PrintStat        = NO;
      m_sluOptions.ConditionNumber  = NO;
      m_sluOptions.Trans            = NOTRANS;
      m_sluOptions.ColPerm          = COLAMD;
    }

template<typename _MatrixType>

const LMatrixType& Eigen::SuperLU< _MatrixType >::matrixL ( ) const [inline]

Definition at line 517 of file SuperLUSupport.h.

    {
      if (m_extractedDataAreDirty) this->extractData();
      return m_l;
    }

template<typename _MatrixType>

const UMatrixType& Eigen::SuperLU< _MatrixType >::matrixU ( ) const [inline]

Definition at line 523 of file SuperLUSupport.h.

    {
      if (m_extractedDataAreDirty) this->extractData();
      return m_u;
    }

template<typename _MatrixType>

const IntColVectorType& Eigen::SuperLU< _MatrixType >::permutationP ( ) const [inline]

Definition at line 529 of file SuperLUSupport.h.

    {
      if (m_extractedDataAreDirty) this->extractData();
      return m_p;
    }

template<typename _MatrixType>

const IntRowVectorType& Eigen::SuperLU< _MatrixType >::permutationQ ( ) const [inline]

Definition at line 535 of file SuperLUSupport.h.

    {
      if (m_extractedDataAreDirty) this->extractData();
      return m_q;
    }

The documentation for this class was generated from the following file:

SuperLUSupport.h
