Sparse supernodal LU factorization for general matrices. More...
#include <SparseLU.h>
Sparse supernodal LU factorization for general matrices.
This class implements the supernodal LU factorization for general matrices. It uses the main techniques from the sequential SuperLU package (http://crd-legacy.lbl.gov/~xiaoye/SuperLU/). It handles transparently real and complex arithmetics with single and double precision, depending on the scalar type of your input matrix. The code has been optimized to provide BLAS-3 operations during supernode-panel updates. It benefits directly from the built-in high-performant Eigen BLAS routines. Moreover, when the size of a supernode is very small, the BLAS calls are avoided to enable a better optimization from the compiler. For best performance, you should compile it with NDEBUG flag to avoid the numerous bounds checking on vectors.
An important parameter of this class is the ordering method. It is used to reorder the columns (and eventually the rows) of the matrix to reduce the number of new elements that are created during numerical factorization. The cheapest method available is COLAMD. See the OrderingMethods module for the list of built-in and external ordering methods.
Simple example with key steps
VectorXd x(n), b(n); SparseMatrix<double, ColMajor> A; SparseLU<SparseMatrix<scalar, ColMajor>, COLAMDOrdering<Index> > solver; // fill A and b; // Compute the ordering permutation vector from the structural pattern of A solver.analyzePattern(A); // Compute the numerical factorization solver.factorize(A); //Use the factors to solve the linear system x = solver.solve(b);
| _MatrixType | The type of the sparse matrix. It must be a column-major SparseMatrix<> |
| _OrderingType | The ordering method to use, either AMD, COLAMD or METIS. Default is COLMAD |
Definition at line 74 of file SparseLU.h.
typedef SparseSolverBase<SparseLU<_MatrixType,_OrderingType> > Eigen::SparseLU< _MatrixType, _OrderingType >::APIBase [protected] |
Definition at line 77 of file SparseLU.h.
| typedef internal::SparseLUImpl<Scalar, StorageIndex> Eigen::SparseLU< _MatrixType, _OrderingType >::Base |
Definition at line 92 of file SparseLU.h.
| typedef Matrix<StorageIndex,Dynamic,1> Eigen::SparseLU< _MatrixType, _OrderingType >::IndexVector |
Reimplemented from Eigen::internal::SparseLUImpl< _MatrixType::Scalar, _MatrixType::StorageIndex >.
Definition at line 90 of file SparseLU.h.
| typedef _MatrixType Eigen::SparseLU< _MatrixType, _OrderingType >::MatrixType |
Reimplemented from Eigen::internal::SparseLUImpl< _MatrixType::Scalar, _MatrixType::StorageIndex >.
Definition at line 82 of file SparseLU.h.
| typedef SparseMatrix<Scalar,ColMajor,StorageIndex> Eigen::SparseLU< _MatrixType, _OrderingType >::NCMatrix |
Definition at line 87 of file SparseLU.h.
| typedef _OrderingType Eigen::SparseLU< _MatrixType, _OrderingType >::OrderingType |
Definition at line 83 of file SparseLU.h.
| typedef PermutationMatrix<Dynamic, Dynamic, StorageIndex> Eigen::SparseLU< _MatrixType, _OrderingType >::PermutationType |
Definition at line 91 of file SparseLU.h.
| typedef MatrixType::RealScalar Eigen::SparseLU< _MatrixType, _OrderingType >::RealScalar |
Reimplemented from Eigen::internal::SparseLUImpl< _MatrixType::Scalar, _MatrixType::StorageIndex >.
Definition at line 85 of file SparseLU.h.
| typedef MatrixType::Scalar Eigen::SparseLU< _MatrixType, _OrderingType >::Scalar |
Definition at line 84 of file SparseLU.h.
| typedef Matrix<Scalar,Dynamic,1> Eigen::SparseLU< _MatrixType, _OrderingType >::ScalarVector |
Reimplemented from Eigen::internal::SparseLUImpl< _MatrixType::Scalar, _MatrixType::StorageIndex >.
Definition at line 89 of file SparseLU.h.
| typedef internal::MappedSuperNodalMatrix<Scalar, StorageIndex> Eigen::SparseLU< _MatrixType, _OrderingType >::SCMatrix |
Definition at line 88 of file SparseLU.h.
| typedef MatrixType::StorageIndex Eigen::SparseLU< _MatrixType, _OrderingType >::StorageIndex |
Definition at line 86 of file SparseLU.h.
| anonymous enum |
Definition at line 94 of file SparseLU.h.
{
ColsAtCompileTime = MatrixType::ColsAtCompileTime,
MaxColsAtCompileTime = MatrixType::MaxColsAtCompileTime
};
| Eigen::SparseLU< _MatrixType, _OrderingType >::SparseLU | ( | ) | [inline] |
Definition at line 100 of file SparseLU.h.
:m_lastError(""),m_Ustore(0,0,0,0,0,0),m_symmetricmode(false),m_diagpivotthresh(1.0),m_detPermR(1) { initperfvalues(); }
| Eigen::SparseLU< _MatrixType, _OrderingType >::SparseLU | ( | const MatrixType & | matrix | ) | [inline, explicit] |
Definition at line 104 of file SparseLU.h.
: m_lastError(""),m_Ustore(0,0,0,0,0,0),m_symmetricmode(false),m_diagpivotthresh(1.0),m_detPermR(1) { initperfvalues(); compute(matrix); }
| Eigen::SparseLU< _MatrixType, _OrderingType >::~SparseLU | ( | ) | [inline] |
Definition at line 111 of file SparseLU.h.
{
// Free all explicit dynamic pointers
}
| Eigen::SparseLU< _MatrixType, _OrderingType >::SparseLU | ( | const SparseLU< _MatrixType, _OrderingType > & | ) | [private] |
| bool Eigen::SparseLU< _MatrixType, _OrderingType >::_solve_impl | ( | const MatrixBase< Rhs > & | B, |
| MatrixBase< Dest > & | X_base | ||
| ) | const [inline] |
Definition at line 217 of file SparseLU.h.
{
Dest& X(X_base.derived());
eigen_assert(m_factorizationIsOk && "The matrix should be factorized first");
EIGEN_STATIC_ASSERT((Dest::Flags&RowMajorBit)==0,
THIS_METHOD_IS_ONLY_FOR_COLUMN_MAJOR_MATRICES);
// Permute the right hand side to form X = Pr*B
// on return, X is overwritten by the computed solution
X.resize(B.rows(),B.cols());
// this ugly const_cast_derived() helps to detect aliasing when applying the permutations
for(Index j = 0; j < B.cols(); ++j)
X.col(j) = rowsPermutation() * B.const_cast_derived().col(j);
//Forward substitution with L
this->matrixL().solveInPlace(X);
this->matrixU().solveInPlace(X);
// Permute back the solution
for (Index j = 0; j < B.cols(); ++j)
X.col(j) = colsPermutation().inverse() * X.col(j);
return true;
}
| Scalar Eigen::SparseLU< _MatrixType, _OrderingType >::absDeterminant | ( | ) | [inline] |
Definition at line 253 of file SparseLU.h.
{
using std::abs;
eigen_assert(m_factorizationIsOk && "The matrix should be factorized first.");
// Initialize with the determinant of the row matrix
Scalar det = Scalar(1.);
// Note that the diagonal blocks of U are stored in supernodes,
// which are available in the L part :)
for (Index j = 0; j < this->cols(); ++j)
{
for (typename SCMatrix::InnerIterator it(m_Lstore, j); it; ++it)
{
if(it.index() == j)
{
det *= abs(it.value());
break;
}
}
}
return det;
}
| void Eigen::SparseLU< MatrixType, OrderingType >::analyzePattern | ( | const MatrixType & | mat | ) |
Compute the column permutation to minimize the fill-in
Definition at line 411 of file SparseLU.h.
{
//TODO It is possible as in SuperLU to compute row and columns scaling vectors to equilibrate the matrix mat.
// Firstly, copy the whole input matrix.
m_mat = mat;
// Compute fill-in ordering
OrderingType ord;
ord(m_mat,m_perm_c);
// Apply the permutation to the column of the input matrix
if (m_perm_c.size())
{
m_mat.uncompress(); //NOTE: The effect of this command is only to create the InnerNonzeros pointers. FIXME : This vector is filled but not subsequently used.
// Then, permute only the column pointers
ei_declare_aligned_stack_constructed_variable(StorageIndex,outerIndexPtr,mat.cols()+1,mat.isCompressed()?const_cast<StorageIndex*>(mat.outerIndexPtr()):0);
// If the input matrix 'mat' is uncompressed, then the outer-indices do not match the ones of m_mat, and a copy is thus needed.
if(!mat.isCompressed())
IndexVector::Map(outerIndexPtr, mat.cols()+1) = IndexVector::Map(m_mat.outerIndexPtr(),mat.cols()+1);
// Apply the permutation and compute the nnz per column.
for (Index i = 0; i < mat.cols(); i++)
{
m_mat.outerIndexPtr()[m_perm_c.indices()(i)] = outerIndexPtr[i];
m_mat.innerNonZeroPtr()[m_perm_c.indices()(i)] = outerIndexPtr[i+1] - outerIndexPtr[i];
}
}
// Compute the column elimination tree of the permuted matrix
IndexVector firstRowElt;
internal::coletree(m_mat, m_etree,firstRowElt);
// In symmetric mode, do not do postorder here
if (!m_symmetricmode) {
IndexVector post, iwork;
// Post order etree
internal::treePostorder(StorageIndex(m_mat.cols()), m_etree, post);
// Renumber etree in postorder
Index m = m_mat.cols();
iwork.resize(m+1);
for (Index i = 0; i < m; ++i) iwork(post(i)) = post(m_etree(i));
m_etree = iwork;
// Postmultiply A*Pc by post, i.e reorder the matrix according to the postorder of the etree
PermutationType post_perm(m);
for (Index i = 0; i < m; i++)
post_perm.indices()(i) = post(i);
// Combine the two permutations : postorder the permutation for future use
if(m_perm_c.size()) {
m_perm_c = post_perm * m_perm_c;
}
} // end postordering
m_analysisIsOk = true;
}
| Index Eigen::SparseLU< _MatrixType, _OrderingType >::cols | ( | void | ) | const [inline] |
Definition at line 133 of file SparseLU.h.
| const PermutationType& Eigen::SparseLU< _MatrixType, _OrderingType >::colsPermutation | ( | ) | const [inline] |
such that
Definition at line 173 of file SparseLU.h.
{
return m_perm_c;
}
| void Eigen::SparseLU< _MatrixType, _OrderingType >::compute | ( | const MatrixType & | matrix | ) | [inline] |
Compute the symbolic and numeric factorization of the input sparse matrix. The input matrix should be in column-major storage.
Definition at line 124 of file SparseLU.h.
{
// Analyze
analyzePattern(matrix);
//Factorize
factorize(matrix);
}
| Scalar Eigen::SparseLU< _MatrixType, _OrderingType >::determinant | ( | ) | [inline] |
Definition at line 337 of file SparseLU.h.
{
eigen_assert(m_factorizationIsOk && "The matrix should be factorized first.");
// Initialize with the determinant of the row matrix
Scalar det = Scalar(1.);
// Note that the diagonal blocks of U are stored in supernodes,
// which are available in the L part :)
for (Index j = 0; j < this->cols(); ++j)
{
for (typename SCMatrix::InnerIterator it(m_Lstore, j); it; ++it)
{
if(it.index() == j)
{
det *= it.value();
break;
}
}
}
return (m_detPermR * m_detPermC) > 0 ? det : -det;
}
| void Eigen::SparseLU< MatrixType, OrderingType >::factorize | ( | const MatrixType & | matrix | ) |
= 0: successful factorization
> 0: if info = i, and i is
<= A->ncol: U(i,i) is exactly zero. The factorization has been completed, but the factor U is exactly singular, and division by zero will occur if it is used to solve a system of equations.
> A->ncol: number of bytes allocated when memory allocation failure occurred, plus A->ncol. If lwork = -1, it is the estimated amount of space needed, plus A->ncol.
Definition at line 496 of file SparseLU.h.
{
using internal::emptyIdxLU;
eigen_assert(m_analysisIsOk && "analyzePattern() should be called first");
eigen_assert((matrix.rows() == matrix.cols()) && "Only for squared matrices");
typedef typename IndexVector::Scalar StorageIndex;
m_isInitialized = true;
// Apply the column permutation computed in analyzepattern()
// m_mat = matrix * m_perm_c.inverse();
m_mat = matrix;
if (m_perm_c.size())
{
m_mat.uncompress(); //NOTE: The effect of this command is only to create the InnerNonzeros pointers.
//Then, permute only the column pointers
const StorageIndex * outerIndexPtr;
if (matrix.isCompressed()) outerIndexPtr = matrix.outerIndexPtr();
else
{
StorageIndex* outerIndexPtr_t = new StorageIndex[matrix.cols()+1];
for(Index i = 0; i <= matrix.cols(); i++) outerIndexPtr_t[i] = m_mat.outerIndexPtr()[i];
outerIndexPtr = outerIndexPtr_t;
}
for (Index i = 0; i < matrix.cols(); i++)
{
m_mat.outerIndexPtr()[m_perm_c.indices()(i)] = outerIndexPtr[i];
m_mat.innerNonZeroPtr()[m_perm_c.indices()(i)] = outerIndexPtr[i+1] - outerIndexPtr[i];
}
if(!matrix.isCompressed()) delete[] outerIndexPtr;
}
else
{ //FIXME This should not be needed if the empty permutation is handled transparently
m_perm_c.resize(matrix.cols());
for(StorageIndex i = 0; i < matrix.cols(); ++i) m_perm_c.indices()(i) = i;
}
Index m = m_mat.rows();
Index n = m_mat.cols();
Index nnz = m_mat.nonZeros();
Index maxpanel = m_perfv.panel_size * m;
// Allocate working storage common to the factor routines
Index lwork = 0;
Index info = Base::memInit(m, n, nnz, lwork, m_perfv.fillfactor, m_perfv.panel_size, m_glu);
if (info)
{
m_lastError = "UNABLE TO ALLOCATE WORKING MEMORY\n\n" ;
m_factorizationIsOk = false;
return ;
}
// Set up pointers for integer working arrays
IndexVector segrep(m); segrep.setZero();
IndexVector parent(m); parent.setZero();
IndexVector xplore(m); xplore.setZero();
IndexVector repfnz(maxpanel);
IndexVector panel_lsub(maxpanel);
IndexVector xprune(n); xprune.setZero();
IndexVector marker(m*internal::LUNoMarker); marker.setZero();
repfnz.setConstant(-1);
panel_lsub.setConstant(-1);
// Set up pointers for scalar working arrays
ScalarVector dense;
dense.setZero(maxpanel);
ScalarVector tempv;
tempv.setZero(internal::LUnumTempV(m, m_perfv.panel_size, m_perfv.maxsuper, /*m_perfv.rowblk*/m) );
// Compute the inverse of perm_c
PermutationType iperm_c(m_perm_c.inverse());
// Identify initial relaxed snodes
IndexVector relax_end(n);
if ( m_symmetricmode == true )
Base::heap_relax_snode(n, m_etree, m_perfv.relax, marker, relax_end);
else
Base::relax_snode(n, m_etree, m_perfv.relax, marker, relax_end);
m_perm_r.resize(m);
m_perm_r.indices().setConstant(-1);
marker.setConstant(-1);
m_detPermR = 1; // Record the determinant of the row permutation
m_glu.supno(0) = emptyIdxLU; m_glu.xsup.setConstant(0);
m_glu.xsup(0) = m_glu.xlsub(0) = m_glu.xusub(0) = m_glu.xlusup(0) = Index(0);
// Work on one 'panel' at a time. A panel is one of the following :
// (a) a relaxed supernode at the bottom of the etree, or
// (b) panel_size contiguous columns, <panel_size> defined by the user
Index jcol;
IndexVector panel_histo(n);
Index pivrow; // Pivotal row number in the original row matrix
Index nseg1; // Number of segments in U-column above panel row jcol
Index nseg; // Number of segments in each U-column
Index irep;
Index i, k, jj;
for (jcol = 0; jcol < n; )
{
// Adjust panel size so that a panel won't overlap with the next relaxed snode.
Index panel_size = m_perfv.panel_size; // upper bound on panel width
for (k = jcol + 1; k < (std::min)(jcol+panel_size, n); k++)
{
if (relax_end(k) != emptyIdxLU)
{
panel_size = k - jcol;
break;
}
}
if (k == n)
panel_size = n - jcol;
// Symbolic outer factorization on a panel of columns
Base::panel_dfs(m, panel_size, jcol, m_mat, m_perm_r.indices(), nseg1, dense, panel_lsub, segrep, repfnz, xprune, marker, parent, xplore, m_glu);
// Numeric sup-panel updates in topological order
Base::panel_bmod(m, panel_size, jcol, nseg1, dense, tempv, segrep, repfnz, m_glu);
// Sparse LU within the panel, and below the panel diagonal
for ( jj = jcol; jj< jcol + panel_size; jj++)
{
k = (jj - jcol) * m; // Column index for w-wide arrays
nseg = nseg1; // begin after all the panel segments
//Depth-first-search for the current column
VectorBlock<IndexVector> panel_lsubk(panel_lsub, k, m);
VectorBlock<IndexVector> repfnz_k(repfnz, k, m);
info = Base::column_dfs(m, jj, m_perm_r.indices(), m_perfv.maxsuper, nseg, panel_lsubk, segrep, repfnz_k, xprune, marker, parent, xplore, m_glu);
if ( info )
{
m_lastError = "UNABLE TO EXPAND MEMORY IN COLUMN_DFS() ";
m_info = NumericalIssue;
m_factorizationIsOk = false;
return;
}
// Numeric updates to this column
VectorBlock<ScalarVector> dense_k(dense, k, m);
VectorBlock<IndexVector> segrep_k(segrep, nseg1, m-nseg1);
info = Base::column_bmod(jj, (nseg - nseg1), dense_k, tempv, segrep_k, repfnz_k, jcol, m_glu);
if ( info )
{
m_lastError = "UNABLE TO EXPAND MEMORY IN COLUMN_BMOD() ";
m_info = NumericalIssue;
m_factorizationIsOk = false;
return;
}
// Copy the U-segments to ucol(*)
info = Base::copy_to_ucol(jj, nseg, segrep, repfnz_k ,m_perm_r.indices(), dense_k, m_glu);
if ( info )
{
m_lastError = "UNABLE TO EXPAND MEMORY IN COPY_TO_UCOL() ";
m_info = NumericalIssue;
m_factorizationIsOk = false;
return;
}
// Form the L-segment
info = Base::pivotL(jj, m_diagpivotthresh, m_perm_r.indices(), iperm_c.indices(), pivrow, m_glu);
if ( info )
{
m_lastError = "THE MATRIX IS STRUCTURALLY SINGULAR ... ZERO COLUMN AT ";
std::ostringstream returnInfo;
returnInfo << info;
m_lastError += returnInfo.str();
m_info = NumericalIssue;
m_factorizationIsOk = false;
return;
}
// Update the determinant of the row permutation matrix
// FIXME: the following test is not correct, we should probably take iperm_c into account and pivrow is not directly the row pivot.
if (pivrow != jj) m_detPermR = -m_detPermR;
// Prune columns (0:jj-1) using column jj
Base::pruneL(jj, m_perm_r.indices(), pivrow, nseg, segrep, repfnz_k, xprune, m_glu);
// Reset repfnz for this column
for (i = 0; i < nseg; i++)
{
irep = segrep(i);
repfnz_k(irep) = emptyIdxLU;
}
} // end SparseLU within the panel
jcol += panel_size; // Move to the next panel
} // end for -- end elimination
m_detPermR = m_perm_r.determinant();
m_detPermC = m_perm_c.determinant();
// Count the number of nonzeros in factors
Base::countnz(n, m_nnzL, m_nnzU, m_glu);
// Apply permutation to the L subscripts
Base::fixupL(n, m_perm_r.indices(), m_glu);
// Create supernode matrix L
m_Lstore.setInfos(m, n, m_glu.lusup, m_glu.xlusup, m_glu.lsub, m_glu.xlsub, m_glu.supno, m_glu.xsup);
// Create the column major upper sparse matrix U;
new (&m_Ustore) MappedSparseMatrix<Scalar, ColMajor, StorageIndex> ( m, n, m_nnzU, m_glu.xusub.data(), m_glu.usub.data(), m_glu.ucol.data() );
m_info = Success;
m_factorizationIsOk = true;
}
| ComputationInfo Eigen::SparseLU< _MatrixType, _OrderingType >::info | ( | ) | const [inline] |
Reports whether previous computation was successful.
Success if computation was succesful, NumericalIssue if the LU factorization reports a problem, zero diagonal for instance InvalidInput if the input matrix is invalidDefinition at line 202 of file SparseLU.h.
{
eigen_assert(m_isInitialized && "Decomposition is not initialized.");
return m_info;
}
| void Eigen::SparseLU< _MatrixType, _OrderingType >::initperfvalues | ( | ) | [inline, protected] |
Definition at line 360 of file SparseLU.h.
| void Eigen::SparseLU< _MatrixType, _OrderingType >::isSymmetric | ( | bool | sym | ) | [inline] |
Indicate that the pattern of the input matrix is symmetric
Definition at line 135 of file SparseLU.h.
{
m_symmetricmode = sym;
}
| std::string Eigen::SparseLU< _MatrixType, _OrderingType >::lastErrorMessage | ( | ) | const [inline] |
Definition at line 211 of file SparseLU.h.
{
return m_lastError;
}
| Scalar Eigen::SparseLU< _MatrixType, _OrderingType >::logAbsDeterminant | ( | ) | const [inline] |
Definition at line 283 of file SparseLU.h.
{
using std::log;
using std::abs;
eigen_assert(m_factorizationIsOk && "The matrix should be factorized first.");
Scalar det = Scalar(0.);
for (Index j = 0; j < this->cols(); ++j)
{
for (typename SCMatrix::InnerIterator it(m_Lstore, j); it; ++it)
{
if(it.row() < j) continue;
if(it.row() == j)
{
det += log(abs(it.value()));
break;
}
}
}
return det;
}
| SparseLUMatrixLReturnType<SCMatrix> Eigen::SparseLU< _MatrixType, _OrderingType >::matrixL | ( | ) | const [inline] |
y = b; matrixL().solveInPlace(y);
Definition at line 146 of file SparseLU.h.
{
return SparseLUMatrixLReturnType<SCMatrix>(m_Lstore);
}
| SparseLUMatrixUReturnType<SCMatrix,MappedSparseMatrix<Scalar,ColMajor,StorageIndex> > Eigen::SparseLU< _MatrixType, _OrderingType >::matrixU | ( | ) | const [inline] |
y = b; matrixU().solveInPlace(y);
Definition at line 156 of file SparseLU.h.
| Index Eigen::SparseLU< _MatrixType, _OrderingType >::rows | ( | void | ) | const [inline] |
Definition at line 132 of file SparseLU.h.
| const PermutationType& Eigen::SparseLU< _MatrixType, _OrderingType >::rowsPermutation | ( | ) | const [inline] |
such that Definition at line 165 of file SparseLU.h.
{
return m_perm_r;
}
| void Eigen::SparseLU< _MatrixType, _OrderingType >::setPivotThreshold | ( | const RealScalar & | thresh | ) | [inline] |
Set the threshold used for a diagonal entry to be an acceptable pivot.
Definition at line 178 of file SparseLU.h.
{
m_diagpivotthresh = thresh;
}
| Scalar Eigen::SparseLU< _MatrixType, _OrderingType >::signDeterminant | ( | ) | [inline] |
Definition at line 309 of file SparseLU.h.
{
eigen_assert(m_factorizationIsOk && "The matrix should be factorized first.");
// Initialize with the determinant of the row matrix
Index det = 1;
// Note that the diagonal blocks of U are stored in supernodes,
// which are available in the L part :)
for (Index j = 0; j < this->cols(); ++j)
{
for (typename SCMatrix::InnerIterator it(m_Lstore, j); it; ++it)
{
if(it.index() == j)
{
if(it.value()<0)
det = -det;
else if(it.value()==0)
return 0;
break;
}
}
}
return det * m_detPermR * m_detPermC;
}
| void Eigen::SparseLU< _MatrixType, _OrderingType >::simplicialfactorize | ( | const MatrixType & | matrix | ) |
bool Eigen::SparseLU< _MatrixType, _OrderingType >::m_analysisIsOk [protected] |
Definition at line 373 of file SparseLU.h.
Index Eigen::SparseLU< _MatrixType, _OrderingType >::m_detPermC [protected] |
Definition at line 390 of file SparseLU.h.
Index Eigen::SparseLU< _MatrixType, _OrderingType >::m_detPermR [protected] |
Definition at line 390 of file SparseLU.h.
RealScalar Eigen::SparseLU< _MatrixType, _OrderingType >::m_diagpivotthresh [protected] |
Definition at line 388 of file SparseLU.h.
IndexVector Eigen::SparseLU< _MatrixType, _OrderingType >::m_etree [protected] |
Definition at line 380 of file SparseLU.h.
bool Eigen::SparseLU< _MatrixType, _OrderingType >::m_factorizationIsOk [protected] |
Definition at line 372 of file SparseLU.h.
Base::GlobalLU_t Eigen::SparseLU< _MatrixType, _OrderingType >::m_glu [protected] |
Definition at line 382 of file SparseLU.h.
ComputationInfo Eigen::SparseLU< _MatrixType, _OrderingType >::m_info [mutable, protected] |
Definition at line 371 of file SparseLU.h.
std::string Eigen::SparseLU< _MatrixType, _OrderingType >::m_lastError [protected] |
Definition at line 374 of file SparseLU.h.
SCMatrix Eigen::SparseLU< _MatrixType, _OrderingType >::m_Lstore [protected] |
Definition at line 376 of file SparseLU.h.
NCMatrix Eigen::SparseLU< _MatrixType, _OrderingType >::m_mat [protected] |
Definition at line 375 of file SparseLU.h.
Index Eigen::SparseLU< _MatrixType, _OrderingType >::m_nnzL [protected] |
Definition at line 389 of file SparseLU.h.
Index Eigen::SparseLU< _MatrixType, _OrderingType >::m_nnzU [protected] |
Definition at line 389 of file SparseLU.h.
internal::perfvalues Eigen::SparseLU< _MatrixType, _OrderingType >::m_perfv [protected] |
Definition at line 387 of file SparseLU.h.
PermutationType Eigen::SparseLU< _MatrixType, _OrderingType >::m_perm_c [protected] |
Definition at line 378 of file SparseLU.h.
PermutationType Eigen::SparseLU< _MatrixType, _OrderingType >::m_perm_r [protected] |
Definition at line 379 of file SparseLU.h.
bool Eigen::SparseLU< _MatrixType, _OrderingType >::m_symmetricmode [protected] |
Definition at line 385 of file SparseLU.h.
MappedSparseMatrix<Scalar,ColMajor,StorageIndex> Eigen::SparseLU< _MatrixType, _OrderingType >::m_Ustore [protected] |
Definition at line 377 of file SparseLU.h.
1.7.6.1
