The base class for the direct and incomplete LU factorization of SuperLU. More...

#include <SuperLUSupport.h>

Inheritance diagram for Eigen::SuperLUBase< _MatrixType, Derived >:

Collaboration diagram for Eigen::SuperLUBase< _MatrixType, Derived >:

Public Types
enum	{ ColsAtCompileTime = MatrixType::ColsAtCompileTime, MaxColsAtCompileTime = MatrixType::MaxColsAtCompileTime }
typedef _MatrixType	MatrixType
typedef MatrixType::Scalar	Scalar
typedef MatrixType::RealScalar	RealScalar
typedef MatrixType::StorageIndex	StorageIndex
typedef Matrix< Scalar, Dynamic, 1 >	Vector
typedef Matrix< int, 1, MatrixType::ColsAtCompileTime >	IntRowVectorType
typedef Matrix< int, MatrixType::RowsAtCompileTime, 1 >	IntColVectorType
typedef Map< PermutationMatrix < Dynamic, Dynamic, int > >	PermutationMap
typedef SparseMatrix< Scalar >	LUMatrixType
Public Member Functions
	SuperLUBase ()
	~SuperLUBase ()
Index	rows () const
Index	cols () const
superlu_options_t &	options ()
ComputationInfo	info () const
	Reports whether previous computation was successful.
void	compute (const MatrixType &matrix)
void	analyzePattern (const MatrixType &)
template<typename Stream >
void	dumpMemory (Stream &)
Protected Types
typedef SparseSolverBase< Derived >	Base
Protected Member Functions
void	initFactorization (const MatrixType &a)
void	init ()
void	extractData () const
void	clearFactors ()
Protected Attributes
LUMatrixType	m_l
LUMatrixType	m_u
IntColVectorType	m_p
IntRowVectorType	m_q
LUMatrixType	m_matrix
SluMatrix	m_sluA
SuperMatrix	m_sluL
SuperMatrix	m_sluU
SluMatrix	m_sluB
SluMatrix	m_sluX
SuperLUStat_t	m_sluStat
superlu_options_t	m_sluOptions
std::vector< int >	m_sluEtree
Matrix< RealScalar, Dynamic, 1 >	m_sluRscale
Matrix< RealScalar, Dynamic, 1 >	m_sluCscale
Matrix< RealScalar, Dynamic, 1 >	m_sluFerr
Matrix< RealScalar, Dynamic, 1 >	m_sluBerr
char	m_sluEqued
ComputationInfo	m_info
int	m_factorizationIsOk
int	m_analysisIsOk
bool	m_extractedDataAreDirty
Private Member Functions
	SuperLUBase (SuperLUBase &)

Detailed Description

template<typename _MatrixType, typename Derived>
class Eigen::SuperLUBase< _MatrixType, Derived >

The base class for the direct and incomplete LU factorization of SuperLU.

Definition at line 291 of file SuperLUSupport.h.

Member Typedef Documentation

template<typename _MatrixType, typename Derived>

typedef SparseSolverBase<Derived> Eigen::SuperLUBase< _MatrixType, Derived >::Base [protected]

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 294 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

typedef Matrix<int, MatrixType::RowsAtCompileTime, 1> Eigen::SuperLUBase< _MatrixType, Derived >::IntColVectorType

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 304 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

typedef Matrix<int, 1, MatrixType::ColsAtCompileTime> Eigen::SuperLUBase< _MatrixType, Derived >::IntRowVectorType

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 303 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

typedef SparseMatrix<Scalar> Eigen::SuperLUBase< _MatrixType, Derived >::LUMatrixType

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 306 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

typedef _MatrixType Eigen::SuperLUBase< _MatrixType, Derived >::MatrixType

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 298 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

typedef Map<PermutationMatrix<Dynamic,Dynamic,int> > Eigen::SuperLUBase< _MatrixType, Derived >::PermutationMap

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 305 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

typedef MatrixType::RealScalar Eigen::SuperLUBase< _MatrixType, Derived >::RealScalar

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 300 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

typedef MatrixType::Scalar Eigen::SuperLUBase< _MatrixType, Derived >::Scalar

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 299 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

typedef MatrixType::StorageIndex Eigen::SuperLUBase< _MatrixType, Derived >::StorageIndex

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 301 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

typedef Matrix<Scalar,Dynamic,1> Eigen::SuperLUBase< _MatrixType, Derived >::Vector

Definition at line 302 of file SuperLUSupport.h.

Member Enumeration Documentation

template<typename _MatrixType, typename Derived>

anonymous enum

Enumerator:

ColsAtCompileTime
MaxColsAtCompileTime

Definition at line 307 of file SuperLUSupport.h.

         {
      ColsAtCompileTime = MatrixType::ColsAtCompileTime,
      MaxColsAtCompileTime = MatrixType::MaxColsAtCompileTime
    };

Constructor & Destructor Documentation

template<typename _MatrixType, typename Derived>

Eigen::SuperLUBase< _MatrixType, Derived >::SuperLUBase ( ) [inline]

Definition at line 314 of file SuperLUSupport.h.

{}

template<typename _MatrixType, typename Derived>

Eigen::SuperLUBase< _MatrixType, Derived >::~SuperLUBase ( ) [inline]

Definition at line 316 of file SuperLUSupport.h.

    {
      clearFactors();
    }

template<typename _MatrixType, typename Derived>

Eigen::SuperLUBase< _MatrixType, Derived >::SuperLUBase ( SuperLUBase< _MatrixType, Derived > & ) [inline, private]

Definition at line 441 of file SuperLUSupport.h.

{ }

Member Function Documentation

template<typename _MatrixType, typename Derived>

void Eigen::SuperLUBase< _MatrixType, Derived >::analyzePattern ( const MatrixType & ) [inline]

Performs a symbolic decomposition on the sparcity of matrix.

This function is particularly useful when solving for several problems having the same structure.

See also:: factorize()

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 351 of file SuperLUSupport.h.

    {
      m_isInitialized = true;
      m_info = Success;
      m_analysisIsOk = true;
      m_factorizationIsOk = false;
    }

template<typename _MatrixType, typename Derived>

void Eigen::SuperLUBase< _MatrixType, Derived >::clearFactors ( ) [inline, protected]

Definition at line 404 of file SuperLUSupport.h.

    {
      if(m_sluL.Store)
        Destroy_SuperNode_Matrix(&m_sluL);
      if(m_sluU.Store)
        Destroy_CompCol_Matrix(&m_sluU);

      m_sluL.Store = 0;
      m_sluU.Store = 0;

      memset(&m_sluL,0,sizeof m_sluL);
      memset(&m_sluU,0,sizeof m_sluU);
    }

template<typename _MatrixType, typename Derived>

Index Eigen::SuperLUBase< _MatrixType, Derived >::cols ( void ) const [inline]

Definition at line 322 of file SuperLUSupport.h.

{ return m_matrix.cols(); }

template<typename _MatrixType, typename Derived>

void Eigen::SuperLUBase< _MatrixType, Derived >::compute ( const MatrixType & matrix ) [inline]

Computes the sparse Cholesky decomposition of matrix

Definition at line 339 of file SuperLUSupport.h.

    {
      derived().analyzePattern(matrix);
      derived().factorize(matrix);
    }

template<typename _MatrixType, typename Derived>

template<typename Stream >

void Eigen::SuperLUBase< _MatrixType, Derived >::dumpMemory ( Stream & ) [inline]

Definition at line 360 of file SuperLUSupport.h.

{}

template<typename MatrixType , typename Derived >

void Eigen::SuperLUBase< MatrixType, Derived >::extractData ( ) const [protected]

Definition at line 681 of file SuperLUSupport.h.

{
  eigen_assert(m_factorizationIsOk && "The decomposition is not in a valid state for extracting factors, you must first call either compute() or analyzePattern()/factorize()");
  if (m_extractedDataAreDirty)
  {
    int         upper;
    int         fsupc, istart, nsupr;
    int         lastl = 0, lastu = 0;
    SCformat    *Lstore = static_cast<SCformat*>(m_sluL.Store);
    NCformat    *Ustore = static_cast<NCformat*>(m_sluU.Store);
    Scalar      *SNptr;

    const Index size = m_matrix.rows();
    m_l.resize(size,size);
    m_l.resizeNonZeros(Lstore->nnz);
    m_u.resize(size,size);
    m_u.resizeNonZeros(Ustore->nnz);

    int* Lcol = m_l.outerIndexPtr();
    int* Lrow = m_l.innerIndexPtr();
    Scalar* Lval = m_l.valuePtr();

    int* Ucol = m_u.outerIndexPtr();
    int* Urow = m_u.innerIndexPtr();
    Scalar* Uval = m_u.valuePtr();

    Ucol[0] = 0;
    Ucol[0] = 0;

    /* for each supernode */
    for (int k = 0; k <= Lstore->nsuper; ++k)
    {
      fsupc   = L_FST_SUPC(k);
      istart  = L_SUB_START(fsupc);
      nsupr   = L_SUB_START(fsupc+1) - istart;
      upper   = 1;

      /* for each column in the supernode */
      for (int j = fsupc; j < L_FST_SUPC(k+1); ++j)
      {
        SNptr = &((Scalar*)Lstore->nzval)[L_NZ_START(j)];

        /* Extract U */
        for (int i = U_NZ_START(j); i < U_NZ_START(j+1); ++i)
        {
          Uval[lastu] = ((Scalar*)Ustore->nzval)[i];
          /* Matlab doesn't like explicit zero. */
          if (Uval[lastu] != 0.0)
            Urow[lastu++] = U_SUB(i);
        }
        for (int i = 0; i < upper; ++i)
        {
          /* upper triangle in the supernode */
          Uval[lastu] = SNptr[i];
          /* Matlab doesn't like explicit zero. */
          if (Uval[lastu] != 0.0)
            Urow[lastu++] = L_SUB(istart+i);
        }
        Ucol[j+1] = lastu;

        /* Extract L */
        Lval[lastl] = 1.0; /* unit diagonal */
        Lrow[lastl++] = L_SUB(istart + upper - 1);
        for (int i = upper; i < nsupr; ++i)
        {
          Lval[lastl] = SNptr[i];
          /* Matlab doesn't like explicit zero. */
          if (Lval[lastl] != 0.0)
            Lrow[lastl++] = L_SUB(istart+i);
        }
        Lcol[j+1] = lastl;

        ++upper;
      } /* for j ... */

    } /* for k ... */

    // squeeze the matrices :
    m_l.resizeNonZeros(lastl);
    m_u.resizeNonZeros(lastu);

    m_extractedDataAreDirty = false;
  }
}

template<typename _MatrixType, typename Derived>

ComputationInfo Eigen::SuperLUBase< _MatrixType, Derived >::info ( ) const [inline]

Reports whether previous computation was successful.

Returns:: Success if computation was succesful, NumericalIssue if the matrix.appears to be negative.

Definition at line 332 of file SuperLUSupport.h.

    {
      eigen_assert(m_isInitialized && "Decomposition is not initialized.");
      return m_info;
    }

template<typename _MatrixType, typename Derived>

void Eigen::SuperLUBase< _MatrixType, Derived >::init ( ) [inline, protected]

Reimplemented in Eigen::SuperLU< _MatrixType >.

Definition at line 394 of file SuperLUSupport.h.

    {
      m_info = InvalidInput;
      m_isInitialized = false;
      m_sluL.Store = 0;
      m_sluU.Store = 0;
    }

template<typename _MatrixType, typename Derived>

void Eigen::SuperLUBase< _MatrixType, Derived >::initFactorization ( const MatrixType & a ) [inline, protected]

Definition at line 365 of file SuperLUSupport.h.

    {
      set_default_options(&this->m_sluOptions);

      const Index size = a.rows();
      m_matrix = a;

      m_sluA = internal::asSluMatrix(m_matrix);
      clearFactors();

      m_p.resize(size);
      m_q.resize(size);
      m_sluRscale.resize(size);
      m_sluCscale.resize(size);
      m_sluEtree.resize(size);

      // set empty B and X
      m_sluB.setStorageType(SLU_DN);
      m_sluB.setScalarType<Scalar>();
      m_sluB.Mtype          = SLU_GE;
      m_sluB.storage.values = 0;
      m_sluB.nrow           = 0;
      m_sluB.ncol           = 0;
      m_sluB.storage.lda    = internal::convert_index<int>(size);
      m_sluX                = m_sluB;

      m_extractedDataAreDirty = true;
    }

template<typename _MatrixType, typename Derived>

superlu_options_t& Eigen::SuperLUBase< _MatrixType, Derived >::options ( ) [inline]

Returns:: a reference to the Super LU option object to configure the Super LU algorithms.

Definition at line 325 of file SuperLUSupport.h.

{ return m_sluOptions; }

template<typename _MatrixType, typename Derived>

Index Eigen::SuperLUBase< _MatrixType, Derived >::rows ( void ) const [inline]

Definition at line 321 of file SuperLUSupport.h.

{ return m_matrix.rows(); }

Member Data Documentation

template<typename _MatrixType, typename Derived>

int Eigen::SuperLUBase< _MatrixType, Derived >::m_analysisIsOk [protected]

Definition at line 437 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

bool Eigen::SuperLUBase< _MatrixType, Derived >::m_extractedDataAreDirty [mutable, protected]

Definition at line 438 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

int Eigen::SuperLUBase< _MatrixType, Derived >::m_factorizationIsOk [protected]

Definition at line 436 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

ComputationInfo Eigen::SuperLUBase< _MatrixType, Derived >::m_info [mutable, protected]

Definition at line 435 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

LUMatrixType Eigen::SuperLUBase< _MatrixType, Derived >::m_l [mutable, protected]

Definition at line 419 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

LUMatrixType Eigen::SuperLUBase< _MatrixType, Derived >::m_matrix [mutable, protected]

Definition at line 424 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

IntColVectorType Eigen::SuperLUBase< _MatrixType, Derived >::m_p [mutable, protected]

Definition at line 421 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

IntRowVectorType Eigen::SuperLUBase< _MatrixType, Derived >::m_q [mutable, protected]

Definition at line 422 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

SluMatrix Eigen::SuperLUBase< _MatrixType, Derived >::m_sluA [mutable, protected]

Definition at line 425 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

SluMatrix Eigen::SuperLUBase< _MatrixType, Derived >::m_sluB [mutable, protected]

Definition at line 427 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

Matrix<RealScalar,Dynamic,1> Eigen::SuperLUBase< _MatrixType, Derived >::m_sluBerr [mutable, protected]

Definition at line 432 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

Matrix<RealScalar,Dynamic,1> Eigen::SuperLUBase< _MatrixType, Derived >::m_sluCscale [mutable, protected]

Definition at line 431 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

char Eigen::SuperLUBase< _MatrixType, Derived >::m_sluEqued [mutable, protected]

Definition at line 433 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

std::vector<int> Eigen::SuperLUBase< _MatrixType, Derived >::m_sluEtree [mutable, protected]

Definition at line 430 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

Matrix<RealScalar,Dynamic,1> Eigen::SuperLUBase< _MatrixType, Derived >::m_sluFerr [mutable, protected]

Definition at line 432 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

SuperMatrix Eigen::SuperLUBase< _MatrixType, Derived >::m_sluL [mutable, protected]

Definition at line 426 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

superlu_options_t Eigen::SuperLUBase< _MatrixType, Derived >::m_sluOptions [mutable, protected]

Definition at line 429 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

Matrix<RealScalar,Dynamic,1> Eigen::SuperLUBase< _MatrixType, Derived >::m_sluRscale [mutable, protected]

Definition at line 431 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

SuperLUStat_t Eigen::SuperLUBase< _MatrixType, Derived >::m_sluStat [mutable, protected]

Definition at line 428 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

SuperMatrix Eigen::SuperLUBase< _MatrixType, Derived >::m_sluU [mutable, protected]

Definition at line 426 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

SluMatrix Eigen::SuperLUBase< _MatrixType, Derived >::m_sluX [mutable, protected]

Definition at line 427 of file SuperLUSupport.h.

template<typename _MatrixType, typename Derived>

LUMatrixType Eigen::SuperLUBase< _MatrixType, Derived >::m_u [mutable, protected]

Definition at line 420 of file SuperLUSupport.h.

The documentation for this class was generated from the following file:

SuperLUSupport.h

Public Types

Public Member Functions

Protected Types

Protected Member Functions

Protected Attributes

Private Member Functions

Detailed Description

template<typename _MatrixType, typename Derived> class Eigen::SuperLUBase< _MatrixType, Derived >

Member Typedef Documentation

Member Enumeration Documentation

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation

template<typename _MatrixType, typename Derived>
class Eigen::SuperLUBase< _MatrixType, Derived >
